10G Base-T Ports | 0 |
SFP+ Ports | 48 |
FC Ports | 0 |
QSFP+ Ports | 6 |
Switching Capacity | 1.44 Tbit/s |
Forwarding Rate | 1,080 Mpps |
Airflow Design | Front-to-back or back-to-front |
Device Virtualization | iStack |
| Super Virtual Fabric (SVF) |
Network Virtualization | M-LAG |
| TRILL |
VM Awareness | Agile Controller |
Network Convergence | FCoE |
| DCBX, PFC, and ETS |
Programmability | OpenFlow |
| OPS |
| Puppet, and OVSDB plugins released on open source websites |
| Linux container for open source and customization programming |
Traffic Analysis | NetStream |
| sFlow |
VLAN | Adding access, trunk, and hybrid interfaces to VLANs |
| Default VLAN |
| QinQ |
| MUX VLAN |
| GVRP |
ACL | Ingress: 3,750 Egress: 1,000 |
MAC Address Table | Maximum: 288k |
| Dynamic learning and aging of MAC addresses |
| Static, dynamic, and blackhole MAC address entries |
| Packet filtering based on source MAC addresses |
| MAC address limiting based on ports and VLANs |
ARP (maximum) | 128k |
IPv4 FIB (maximum) | 256k |
IP Routing | IPv4 routing protocols, such as RIP, OSPF, BGP, and IS-IS |
| IPv6 routing protocols, such as RIPng, OSPFv3, IS-ISv6, and BGP4+ |
IPv6 FIB (maximum) | 128k |
IPv6 | IPv6 Neighbor Discovery (ND) |
| Path MTU Discovery (PMTU) |
| TCP6, ping IPv6, tracert IPv6, socket IPv6, UDP6, and Raw IP6 |
Multicast FIB (maximum) | 8k |
Multicast | IGMP, PIM-SM, PIM-DM, MSDP, and MBGP |
| IGMP snooping |
| IGMP proxy |
| Fast leave of multicast member interfaces |
| Multicast traffic suppression |
| Multicast VLAN |
Reliability | LACP |
| STP, RSTP, VBST, and MSTP |
| BPDU protection, root protection, and loop protection |
| Smart Link and multi-instance |
| DLDP |
| ERPS (G.8032) |
| VRRP, VRRP load balancing, and BFD for VRRP |
| BFD for BGP/IS-IS/OSPF/Static route |
QoS | Traffic classification based on Layer 2 headers, Layer 3 protocols,
Layer 4 protocols, and 802.1p priority |
| Actions of ACL, CAR, re-marking, and scheduling |
| Queue scheduling algorithms, including PQ, WRR, DRR, PQ + WRR, and
PQ + DRR |
| Congestion avoidance mechanisms, including WRED and tail drop |
| Traffic shaping |
Configuration and Maintenance | Console, Telnet, and SSH terminals |
| Network management protocols, such as SNMPv1/v2c/v3 |
| File upload and download through FTP and TFTP |
| BootROM upgrade and remote upgrade |
| 802.3az Energy Efficient Ethernet (EEE) |
| Hot patches |
| User operation logs |
| ZTP |
Security and Management | 802.1x authentication |
| Command line authority control based on user levels, preventing
unauthorized users from using commands |
| DoS, ARP, and ICMP attack defenses |
| Port isolation, port security, and sticky MAC |
| Binding of the IP address, MAC address, interface number, and VLAN
ID |
| Authentication methods, including AAA, RADIUS, and HWTACACS |
| Remote Network Monitoring (RMON) |
Dimensions (W x D x H) | 442 mm x 420 mm x 43.6 mm |
Weight (fully loaded) | 8.7 kg (19.2 lb) |
Environmental Parameters | Operating temperature: 0°C to 40°C (32°F to 104°F) (0m to 1,800m)
Storage temperature: -40°C to 70°C (-40°F to 158°F)
Relative humidity: 5% RH to 95% RH, non-condensing |
Operating Voltage | AC: 90V to 290V
DC: -38.4V to -72V |
Max. Power Consumption | 245W |
