Frequency Servers 4 Gpu Cards and Dual Cpu in Original 4U Design for Optimal Efficiency

Product Description
Frequency Servers 4 Gpu Cards and Dual Cpu in Original 4U Design for Optimal Efficiency
Frequency Servers 4 Gpu Cards and Dual Cpu in Original 4U Design for Optimal Efficiency
Frequency Servers 4 Gpu Cards and Dual Cpu in Original 4U Design for Optimal Efficiency
Frequency Servers 4 Gpu Cards and Dual Cpu in Original 4U Design for Optimal Efficiency
Frequency Servers 4 Gpu Cards and Dual Cpu in Original 4U Design for Optimal Efficiency
Specification
Product Description
Product Name
LY-X11D2A SERVER
CPU
Supports two In tel Xeon Scalable first and second generation CPUs with LGA3647 socket.
Maximum support for 205W per CPU.
Maximum support for 28 cores per CPU.
RAM
DDR4 ECCREGS 16G 2666*4
Motherboard
LY-X11D2A supports 4x dual-width GPUs
Power supply
2200W (1+1) redundant power supply
Southbridge
C621 chipset
BMC
ASPEED AST2500
Audio chip
ALC897
Network chip
1210-AT*2
RAM
Support for 16 memory
Up to 2TB In tel Optane Persistent Memory 200 Series, DDR4-2666MHZ
Up to 4TB 3DS ECC LRDIMM, DDR4-2933MHz
Up to 4TB 3DS ECC RDIMM DDR4-2933MHz
Up to 2TB In tel Optane DC Persistent Memory in memory mode (Cascade Lake only).
Supported Memory Frequencies
2933/2666/2400/2133 MT/S ECC DDR4 LRDIMM(3DS),RDIMM (3DS).
Single Memory Stick Capacity
LRDIMM:128GB,256GB RDIMM:64GB,128G.
PCLE
6 x PCle 3.0 x16,
1 x PCle 3.0 x4 (in x8 slot)
1 x M.2 Interface: PCle 3.0 x4 Form Factor: 22110, 2280 Key: M-Key
1 x COM pin header(2.54mm pitch 9pin)
Motherboard Interface
2 x 8087 interfaces support 8 x SATA3.0
2 x SATA3.0 interfaces
1 x USB3.0 header, supporting two USB3.0
1 x USB2.0 header, supporting two USB2.0
1 x HD AUDIO Header
I/O
1 x VGA DB15
2 x 1000M/100M/10M bps auto-negotiation network ports
2 x USB3.0 + remote management network port
1 x COM DB9 interface
Temperature
Operating: 0 to 60°C Storage: -20 to 75°C.
Humidity
5 to 95% RH (non-condensing).
Company Profile
Frequency Servers 4 Gpu Cards and Dual Cpu in Original 4U Design for Optimal Efficiency
Frequency Servers 4 Gpu Cards and Dual Cpu in Original 4U Design for Optimal Efficiency
Frequency Servers 4 Gpu Cards and Dual Cpu in Original 4U Design for Optimal Efficiency
Frequency Servers 4 Gpu Cards and Dual Cpu in Original 4U Design for Optimal Efficiency
Packing & Delivery
Frequency Servers 4 Gpu Cards and Dual Cpu in Original 4U Design for Optimal Efficiency
FAQ
Frequency Servers 4 Gpu Cards and Dual Cpu in Original 4U Design for Optimal Efficiency
